The remastered CoilMaster™ (IM50S) is a lightweight cordless system to get the job done no matter the coil application. The CoilMaster™ is the only purpose-built cordless tool designed for Australian job sites. It covers all coil applications (27-50mm) from cladding, bracing, tile underlay and more. Making it a must-have versatile tool to keep in your kit.
Introducing the latest PASLODE COILMASTER™ |
Ash from Create Building Co.
Ash at Create Building Co., are experts in high-end residential builds, extensions, and renovations. They’ve been using Paslode’s CoilMaster™ for a range of projects, including tile underlay and James Hardie weatherboard planks. The CoilMaster™ has helped them be more productive and get the job done faster.
From Hammer and Nails to the PASLODE COILMASTER™ | Nick from NcCarpentry
Hear from Nick at NCCarpentry, currently working on 212 Ballarat Road, about why they choose Paslode. Previously using hammer and nails, Nick now relies on the cordless Paslode CoilMaster™, which allows for continuous firing. Saves them from a sore arm and at least an hour on the job.
JPC Team Upgrades to Paslode CoilMaster™ for Effortless Weatherboarding
The JPC team were used to the hassle of hoses and compressors, but switching to the latest CoilMaster™ has been a game changer. Putting it to work to nail weatherboards from start to finish — the lightweight cordless CoilMaster™ makes it easy.
Watch Videos On YouTube
For more tips, job-site success stories and product videos subscribe to our YouTube channel.
Specifications
The CoilMaster™ IM50S is only available in Australia.
Features
- Same Lithium-Ion Battery across the Paslode Impulse family
- Lithium-Ion battery drives 4,500 shots per 1 hour charge time
- Quick release Jam clear in the event of a Jam
- Paslode impulse technology: Cordless convenience means no hoses, no compressors, pick up and go
- Ergonomic design with non-slip hand grip to improve comfort and safety
- Removable No Mar Tip, adjustable nail tray & longer fan run time for enhanced performance
- Varied and versatile applications with a range of 27-50mm nails for applications including cladding, fibre cement, plywood, ply bracing, eaves and soffits, fencing, unpunched metal connectors, strap bracing, decking and cement tile underlay.
- *Not recommended for use with joist hangers
Previous models
| Specifications | |
|---|---|
| Model Name | IM50S |
| Product Code | B50001 |
| Weight | 2.95kg |
| Dimensions (L x H x W) | 310mm x 335mm x 120mm |
| Fastener Range | 27-50mm |
| Cycle Rate | 2 nails / second intermittently |
| Magazine Capacity | 200 (approx.) |
| Fuel Cell Life | 800 Nails (approx.) |
| Collation Angle | 0° |
| Battery Life | 4,500 shots per charge |
| Applications |
|---|
| Cladding (James Hardie, Weathertex, timber, etc.) |
| Fibre Cement (Villaboard, Eaves, Tile underlay, etc.) |
| Plywood |
| Ply bracing |
| Fencing (only softwood) |
| Decking |
| Cement tile underlay |
| Unpunched metal connectors |
| Strap bracing |
Gallery
Fastener Charts
Nails Compatible with the new Paslode CoilMaster™
Here’s a list of recommended fasteners to use with your Paslode CoilMaster™.
impulse value packs
| Product Code | Length | Diameter | Shank Type | Finish | Fuel Cells | Box Qty |
|---|---|---|---|---|---|---|
| B40025 | 27mm | 2.5mm | Ring | Hot Dipped Galv | 3 | 2400 |
| B40020 | 32mm | 2.5mm | Screw | Galvanised | 3 | 2400 |
| B40027 | 32mm | 2.7mm | Smooth | Hot Dipped Galv | 3 | 2400 |
| B40021 | 45mm | 2.5mm | Ring | Hot Dipped Galv | 3 | 2400 |
| B40022 | 50mm | 2.5mm | Ring | Hot Dipped Galv | 3 | 2400 |
| B40024 | 50mm | 2.5mm | Ring | Stainless Steel | 2 | 1600 |
